CAD: Tanner Suite

The Tanner Suite offers products for the design, layout, and verification of analog, mixed signal, and MEMS designs. It consists of fully-integrated front-end and back-end tools, from schematic capture, circuit simulation, and waveform probing to physical layout and simulation.

The tools included in the suite are:

• L-Edit—tool for layout design, LVS, and, DRC (can also be used for MEMS designs); for more details, see http://www.tannereda.com/images/pdfs/Datasheets/DS_LEdit.pdf.
• S-Edit—tool for schematic capture; for more details, see http://www.tannereda.com/images/pdfs/Datasheets/DS_SEditSchemCap.pdf.
• T-Spice—tool for circuit simulation; for more details, see http://www.tannereda.com/images/pdfs/Datasheets/DS_TSpice_datasheet.pdf.
• W-Edit—waveform viewing and analysis; for more details, see http://www.tannereda.com/images/pdfs/Datasheets/DS_TSpice_datasheet.pdf.
